Features
Model WBK-9000 |
|||
Spindle Travel |
9.875”/251mm | Spindle Speed | 70,88,118RPM |
Spindle Feed Speed |
0.002”/0.05mm-0.02”/0.5mm Rev | Cross Feed Speed | 0.002”/0.05mm-0.01”/0.25mm Rev |
HandwheelGraduatiions |
0.002”/ 0.05mm | Rotor Diameter | 7”/180mm-18”/457mm |
Rotor Thickness |
4” /102mm | Drum Diameter | 6”/152mm-28”/711mm |
Drum Depth |
9.875” /251mm | Motor | 110V/220V/380V,50/60Hz |
Gross Weight |
400KG | Dimension | 1100x1070x1140mm |
