Features
- Aisle type installation in order to a vehicle go through between two camera poles. Very flexible and convenient for two entries(front and rear) tyre shop.
- Third camera automatic calibration between two camera poles is to maximize accuracy, and installation convenience.
- Durable 4X4 target boards with rubber protection.
- All new 3 point clamps are lighter with rim scratch proof.
- Caster, camber, and toe dynamic adjustments now are applied to the system.
- The most flexible camera installation on wall, floor, and ceiling. Just suit to your shop.
- Wider camera range to capture more accurate data.
- After-sales-service becomes more simple you will never see. The fastest camera or reflection board replacement with exactly same accuracy. Owner will save 80% time to wait for our service, and save 60% money to pay for maintenance.
- 3 years warranty from factory in Malaysia. T&C apply.
Technical Specifications |
|
Power supply |
220V/50~60HZ/1PH |
Display resolution |
0.01˚/1' |
Measure accuracy |
0.02˚/1' |
Total Toe |
±20˚ |
Individual Toe |
±10˚ |
Total turn angle
|
±58˚ |
Camber |
±10˚ |
Caster | ±20˚ |
KPI | ±20˚ |
Included angle | 0~30˚ |
